Regular price €499,00 Sale price€399,00
/


Upgraded 1,800W MPPT

Step into the sun with greater power - Boosted MPPT unleashes stronger solar potential for bigger systems and brighter futures. 1800W MPPT supports up to 2400W solar panel, allowing higher wattage panels for increased energy harvest and system design flexibility.
1800W MPPT

Up to 2,400W solar panel compatibility for full-sun performance

Supports up to 2400W of solar panel for connection to high-wattage solar panels, harnessing more energy from the sun. Store more power for greater energy independence and self-sufficiency.

Dual MPPT for maximum power generation and efficiency

Dual MPPT tracks max power point of two solar arrays independently, improving efficiency, reliability and flexibility of the PV system.
FAQS
What is the difference between Hub 2000 and PVHub 1200?

The Hub 2000 can access higher power PV panels, supporting up to 2,400W. The payback cycle for the Hub 2000 is less than 3 years when used in combination with 2 AB2000's,and 2,000W of PV panels.

What are the model names, dimensions, and weights of each SolarFlow component?

Hub 2000 Model: ZDHUB2000, dimensions (W x D x H): 363 × 64 × 246 mm, weight ≈ 5.2 kg;

Battery Model: ZDAB1000, dimensions (W x D x H): 350 × 200 × 187 mm, weight ≈ 11.5 kg;

Battery Model: ZDAB2000, dimensions (W x D x H): 350 × 200 × 298mm, weight ≈ 21.62 kg.

Can I purchase SolarFlow without paying VAT in Germany?

Yes. According to the German Value Added Tax Act (UStG) § 12 tax rates, you can buy SolarFlow without VAT

For a better shopping experience, we recommend visiting our German website to enjoy tax-free prices on your orders.

What devices do I need for a balcony energy storage system?

The balcony energy storage system includes solar panels, SolarFlow and micro-inverters. You can shop for PVHub and Hoymiles micro-inverters on the order page.

How can I benefit from using SolarFlow?

Solar panels often produce more power than a home needs at various points throughout the day. The excess energy is fed to the grid with no benefit to the person who generated it. SolarFlow lets you make the most of your solar panels by routing the extra energy to at-home storage so you can use it later and reduce your energy costs.

What is SolarFlow's capacity?

SolarFlow's compatible energy storage modules include AB1000 with 960Wh of storage and AB2000 with 1,920Wh. Up to four batteries can be stacked in any combination, for a maximum total capacity of 7,680Wh.

How many solar panels can be connected with SolarFlow?

The Hub 2000 has two MPPTs, 900W each and 1,800W in total. In order to utilize your solar system more efficiently, we recommend connecting each MPPT in parallel to solar panels with a total power of 1,000W, to maximize yield even when the sunlight isn't as strong. Please remember, for your safety, that the voltage of the PV panels accessed by each MPPT should be between 16V and 60V, and the current should not exceed 32A.

What kind of solar panel is suitable for SolarFlow?

Each of Hub 2000's MPPTs is compatible with solar panels delivering a voltage between 16V and 60V and less than 32A of current. For each MPPT input, if connecting more than one solar panel, the panels must be wired in parallel.

What is the difference between AB1000 and AB2000?

At 1,920Wh, AB2000 has twice the capacity of AB1000 and is smaller in size than two AB1000's stacked together. AB2000 also has an automatic self-heating function that allows it to work in ambient temperatures as low as -20°C.

Can the AB1000 be used together with the AB2000?

Yes, your solar system can include a total of four AB1000 and/or AB2000 batteries stacked together. However, AB1000 can only operate in ambient temperatures of 0°C and above whereas AB2000 works as low as -20°C. In addition, you can only stack 4 Batteries at most.

What safety certifications does SolarFlow have?

FCC, CA65, CE, RoSH, REACH, TÜV Mark and TÜV CE

I am new to solar products. How can I set up my balcony power plant system with storage?

Step 1: You'll need to check your local regulations to find out how much power the balcony power station can provide to your household's circuts. Nowadays it's typically around 600W or 800W.

Step 2: We recommend choosing panels that can deliver a total of 2,000W, with 1,000W going to each MPPT.

Step 3: When choosing a battery configuration, it's ideal if the amount of energy you can store is equal to the amount of energy produced in one day.

How is available power destributed between the home and storage (AB1000/AB2000)?

The Zendure App lets you set the amount of power going to your home via the micro-inverter, and excess power will be distributed to storage in the AB1000 or AB2000 batteries.

When is the battery charged and discharged?

If the PV power is greater than the micro inverter power set in the Zendure app, the batteries are charged. Otherwise, stored energy is discharged to cover the deficit. If your balcony power plant is equipped with both AB1000 and AB2000, the AB2000 switches on the self-heating function in cold weather from 0°C to -20°C, while the AB1000 only starts to work when the temperature rises to 0°C again.

How can I determine my daily energy consumption?

Determining your daily energy consumption is an important step in configuring the right system for your needs. The goal is to generate more energy than you need during the day so that the surplus energy is stored and is sufficient to cover your evening consumption.

After sunset, check your energy meter and write down the reading. Then, after sunrise, take another reading and write this down. The difference between these two figures is the energy consumed. At the next sunset, read the meter again and subtract the sunrise figure to calculate the energy you used during the day.

Please keep in mind that energy usage and daylight availability fluctuate depending on the weather and the season. It may be helpful to project energy consumption for other seasons by checking the rated power consumption of your major appliances and anticipating how much more/less they will be used throughout the year. Power consumption information is often provided by the manufacturer but can also be determined using smart plugs with energy monitoring capability.

Are the PVHub and batteries shipped separately?

Yes, the PVHub and each storage unit are shipped in separate boxes, which may or may not be delivered at the same time. If more than seven days have passed since receiving a package, and you're still waiting for the rest of your order to arrive, please contact us..

Specs
PV Hub Hub 2000 View Spec
